Product > Projectors > High Brightness Projector > Ricoh PJ WU5570
Smart Compact Projector
Ricoh PJ WU5570
Features and Benefits
Smart Compact Projector Ricoh PJ WU5570
Powerful image projection allows screening from 30 to 300 inches providing a wide choice of screening rooms and auditoriums. Two HDMI ports, including one MHL enabled, allow connection of mobile devices including smart phones. You can also connect a range of input devices such as network PCs and even video HD sources like Blu-ray players.
Powerful image projection allows screening from 30 to 300 inches providing a wide choice of screening rooms and auditoriums. Two HDMI ports, including one MHL enabled, allow connection of mobile devices including smart phones. You can also connect a range of input devices such as network PCs and even video HD sources like Blu-ray players.
- The ideal high quality digital projector for audiences from 10 to 50 people
- WUXGA 1920 x 1200 pixel resolution for screening HD quality content from a range of HD input sources
- Two integral 10W speakers allow AV presentations without additional amplified external sound system
- Vertical and horizontal lens shift with keystone correction gives complete flexibility in installation location
- Eco Mode extends lamp life up to 4,000 hours (292 W) reduces replacement time and saves energy
- USB port means that you can screen slideshows without the need for a computer connection
Specifications
- General
- Ecology
|
Projection system |
Single chip DLP |
|
Resolution |
PJ X5580: 1,024 x 768 , PJ WU5570: 1,920 x 1,200 |
|
Panel |
PJ X5580: 0.7 inch , PJ WU5570: 0.67 inch |
|
Aspect ratio |
PJ X5580: 4:3, PJ WU5570: 16:10 |
|
Brightness |
PJ X5580: 6,000 lumen, PJ WU5570: 5,500 lumen |
|
Contrast ratio |
9,000:1 |
|
Projection screen size |
30" to 300" |
|
Projection distance |
1 to 13.5 m (from rear of unit to projection surface) |
|
Throw ratio |
PJ X5580: 1.3-2.2, PJ WU5570: 1.2-2.2 |
|
Lamp |
Mercury lamp |
|
Lamp life |
Standard: 3,000 hours (365 W), Eco mode 1: 4,000 hours |
|
Zoom ratio |
1.8 |
|
Zoom |
Manual |
|
Focus |
Manual |
|
Connection terminal |
Mini D-SUB15pin x 2 (Computer IN), Mini D-SUB15pin x 1 (Monitor OUT), Mini DIN 4pin x 1 (S-Video), RCA_1pin x 1 (Video), D-SUB 9pin x 1 (PC Control), HDMI 1/ MHL in x1, HDMI 2 in x1, Display port x1, 3.5 mm mini Jack x1/x2 , RCA audio jack (Left/Mono) x1, RCA audio jack (Right) x1 |
|
USB |
Type-A x 1 |
|
Wired LAN |
RJ-45 x 1 (10BASE-T/100BASE-TX/1000BASE-T) |
|
Wireless LAN |
LAN IEEE 802.11b/g/n compliant |
|
Primary features |
Mute (Blank), Freeze, Re-size (Magnify), Auto keystone, Password protection, User logo, Eco mode, 3D Ready, Wall Color mode, Kensington lock, Firmware update |
|
Built-in speaker |
10 W x 2 |
|
Dimensions (W x D x H) |
424 x 356 x 150 mm |
|
Weight |
6.35 kg |
|
Power source |
100 - 240 V, 50/60 Hz |
|
Sound power level (full system) |
35 dB |
|
Power consumption - Operating power |
495 W |
|
Power consumption - Energy Saver Mode |
395 W |
|
Power consumption - Stand-by mode |
1 W |
|
Operating temperature |
5°C - 40°C |
|
Operating humidity |
20% - 80% |
|
Storage conditions - Temperature |
-20°C - 60°C |
|
Storage conditions - Humidity |
20% - 80% |
