Ricoh fi Series
fi-8270
ADF & Flatbed Document Scanner
High-efficiency commercial scanner featuring 70 ppm / 140 ipm ADF speeds, built-in flatbed, iSOP sound-detection protection, and robust 10,000 daily sheets capacity.
01
70 ppm ADF
02
140 ipm Duplex
03
Built-in Flatbed
04
PaperStream
Fast Duplex ADF
70 ppm / 140 ipm.
Integrated Flatbed
1.7s per page capture.
Daily Capacity
Up to 10,000 sheets/day.
Advanced iSOP
Sound detection jams protection.
Applications of Ricoh fi-8270 in Malaysia
The Ricoh fi-8270 brings high-speed automatic feeding and reliable flatbed versatility to corporate environments, legal firms, and financial counters across Malaysia.
Legal & Corporate Back-Office
- High-speed batch digitization of contracts and case files
- Flatbed scanning for fragile bindings or bound volumes
- Consistent image quality using PaperStream IP optimization
- Seamless multi-page automated processing
Customer Service & Counters
- Rapid ID card and passport capture on the flatbed
- Dual capability for both loose sheets and thick booklets
- Compact integration for shared reception desk spaces
- Fast workflows minimizing customer waiting times
Finance & Administration
- Robust 10,000 sheets daily volume for invoice processing
- Ultrasonic multi-feed detection for mixed paper weights
- Direct network or high-speed USB 3.2 data connection
- Reliable paper protection reducing manual interventions
Why Malaysian Businesses Choose fi-8270
Organizations prefer the fi-8270 for its dual ADF and flatbed convenience alongside enterprise performance:
- 70 ppm / 140 ipm high-speed duplex ADF performance
- Color CCD Flatbed fast 1.7 sec/page scan rate
- 10,000 Sheets Daily heavy-duty operations capacity
- iSOP Sound Protection intelligent feed monitoring
- Ethernet & USB 3.2 flexible enterprise integration
- PaperStream IP advanced image cleanup driver
The ideal choice for Malaysian businesses requiring robust ADF throughput and integrated flatbed scanning capabilities.
Details
Specifications
Video
Brochure
Comprehensive Overview: fi-8270
The Ricoh fi-8270 integrates an automatic 100-sheet document feeder with a high-speed flatbed glass surface. It handles everything from thin receipts to heavy cardstock and bound booklets securely.
Dual Feeding & Flatbed
- • ADF Speed: 70 ppm / 140 ipm duplex scanning.
- • Flatbed Integration: Fast 1.7 second color capture per page.
- • ADF Capacity: 100 sheets holding volume.
Smart Protection
- • iSOP Technology: Stops feeding when abnormal sound is detected.
- • Ultrasonic Sensors: Detects multi-sheet overlaps accurately.
- • PaperStream IP: Advanced image cleanup driver.
Technical Specifications
Performance
- Scan Speed: 70 ppm / 140 ipm (ADF), 1.7 sec/page (Flatbed)
- Scan Mode: Color, Grayscale, Monochrome
- Optical Resolution: 600 dpi
- Light Source: RGB LED x 2 (ADF) / White LED (Flatbed)
Interface & Size
- Interface: USB 3.2 Gen 1x1 / Ethernet (10/100/1000BASE-T)
- Max Document Size: 215.9 x 355.6 mm (ADF) / 215.9 x 297 mm (Flatbed)
- Dimensions: 300 x 577 x 234 mm
Handling Capacity
- ADF Capacity: 100 sheets
- Expected Daily Volume: 10,000 sheets
- Multifeed Detection: Ultrasonic overlap sensor + Length
Compatibility
- OS Support: Windows 11/10, Windows Server, Linux
- Drivers: PaperStream IP (TWAIN/ISIS), WIA
- Power Requirement: AC 100 to 240 V
- Weight: 8.8 kg
Will be updated soon
Will be updated soon
Comparison Overview
| Feature | Ricoh fi-8270 | Compact ADF Scanner | Flatbed Scanner |
|---|---|---|---|
| Scan Speed | 70 ppm / 140 ipm | 40 ppm / 80 ipm | 10-15 sec/page |
| Scanning Type | ADF + Built-in Flatbed | ADF only | Flatbed glass only |
| ADF Capacity | 100 Sheets | 20 sheets | N/A |
| Daily Duty Cycle | 10,000 Sheets | 4,500 sheets | Low volume |
| Malaysia Supplier Support | Yes ✔ | Limited | Limited |
§ 03
Frequently asked questions
The fi-8270 delivers fast speeds of 70 pages per minute (simplex) and 140 images per minute (duplex) via the automatic feeder.
Yes! It features an integrated color CCD flatbed capable of scanning pages at 1.7 seconds per page alongside the 100-sheet ADF.
iSOP (Intelligent Sonic Paper Protection) monitors the sound of paper feeding and automatically halts the process if anomalous noise indicates a potential jam.
We provide full installation, setup guidance, and maintenance support across Malaysia for the fi-8270 scanner series.
