Ricoh fi Series
fi-8170
A4 ADF Document Scanner
Compact and powerful A4 automatic document feeder scanner engineered with Clear Image Capture technology, robust paper feeding mechanisms, and high-speed duplex enterprise scanning.
01
Load ADF
02
70 PPM Speed
03
PaperStream
Capture
70 PPM / 140 IPM
Blazing fast duplex capture (A4 portrait).
100-Sheet ADF
Large batch capacity.
Automatic Separation
Reliable mixed & thick media feeding.
USB & Ethernet
Flexible connectivity options.
Details
Specifications
Video
Brochure
Comprehensive Overview: Ricoh fi-8170
The Ricoh fi-8170 delivers industry-leading A4 scanning with Clear Image Capture technology, Automatic Separation Control, and robust multi-feed detection designed to maximize corporate workflows and reliable everyday document processing.
Smart Design & Usability
- • Clear Image Capture: Industry-leading OCR accuracy and true-to-life document rendering.
- • Automatic Separation Control: Adapts torque dynamically to match batch thicknesses for smooth feeding.
- • Versatile Connectivity: Supports both USB 3.2 and 1000Base-T wired LAN networking.
Advanced Processing & Power
- • PaperStream IP & Capture: Enterprise driver automation, image cleanup, and batch sorting.
- • Corner-to-Corner Protection: Detects skewed or jammed feeds instantly to avoid paper tears.
- • Passport & Card Support: Scans passports and thick plastic ID cards effortlessly without extra carrier sheets.
Technical Specifications
Performance
- Scan Speed (A4 Portrait): 70 ppm / 140 ipm (200/300 dpi)
- ADF Capacity: 100 sheets (A4 80 g/m²)
- Daily Duty Cycle: 10,000 sheets/day
- Optical Resolution: 600 dpi
Interface & Size
- Interface: USB 3.2 Gen 1x1 / Ethernet (10BASE-T, 100BASE-TX, 1000BASE-T)
- Max Document Size: 216 x 355.6 mm (Long document up to 6,096 mm)
- Dimensions: 300 x 170 x 163 mm
- Weight: 3 kg
Advanced Functions
- Multi-feed Detection: Ultrasonic sensor & manual skip
- Paper Protection: Sound detection & image monitoring
- Automatic Separation Control: Yes
- Background Color: White / Black (selectable)
Compatibility
- OS Support: Windows 11, 10, Server editions, Linux
- Software: PaperStream IP / Capture, Scanner Central Admin
- Power Requirements: AC 100 to 240 V, 50/60 Hz
- Environmental: ENERGY STAR, RoHS
Will be updated soon
Will be updated soon
Applications of Ricoh fi-8170 in Malaysia
The Ricoh fi-8170 provides high-speed, compact A4 departmental scanning tailored for corporate reception desks, bank counters, and medical records across Malaysia.
Corporate & Front Desk
- Rapid customer verification via direct passport and ID card scanning
- Reliable multi-feed detection for mixed customer document batches
- Durable construction built for busy daily operation up to 10,000 sheets
- Compact footprint optimized for tight counter spaces
Banking & Financial
- Instant processing of counter transactions and identification forms
- Accurate automated text capture for fast data entry workflows
- Secure document handling with automatic torque adjustments
- Seamless back-office integration via network or USB connectivity
Healthcare & Administration
- Efficient daily processing of patient registration and medical forms
- High throughput capacity up to 10,000 sheets per day
- Reduced manual intervention with smart automatic adjustments
- Consistent performance under high daily counter demands
Why Malaysian Enterprises Choose Ricoh fi-8170
Organizations choose the fi-8170 for its superior OCR capture, passport feeding efficiency, and network readiness:
- 70 PPM / 140 IPM scanning speed in color or monochrome (portrait)
- 100-Sheet ADF capacity for continuous multi-page intake
- Direct Passport Scanning without requiring carrier sheets
- Network Connectivity with built-in Ethernet port
- 10,000 Sheets/Day daily duty recommended volume
- PaperStream IP & Click simplifies capture workflows
The ultimate departmental productivity solution for Malaysian offices requiring rapid, flawless A4 document workflows.
Comparison Overview
| Feature | Ricoh fi-8170 | Ricoh fi-70F | Standard Flatbed |
|---|---|---|---|
| Scan Speed | 70 PPM / 140 IPM | 1.0 second per page | 10-15 seconds |
| Operation Type | ADF (100 sheets) / Passport Ready | Coverless Flatbed | Lid-Press Flatbed |
| Daily Duty Cycle | 10,000 sheets/day | Low volume | Low volume |
| Max Document Size | A4 / Passport / Long document | A6 (IDs, Passports) | A4 / A3 |
| Malaysia Supplier Support | Yes ✔ | Yes ✔ | Limited |
§ 03
Frequently asked questions
The fi-8170 delivers an impressive scanning speed of up to 70 pages per minute (ppm) and 140 images per minute (ipm) in duplex (A4 portrait at 200 or 300 dpi).
It is recommended for departmental usage with a high daily throughput capacity of up to 10,000 sheets per day.
Yes, the fi-8170 is designed to capture passports and identification booklets directly through the ADF without needing a separate carrier sheet.
Yes, we provide full technical support, setup guidance, and maintenance options across Malaysia for the Ricoh fi-8170.
The scanner comes bundled with PaperStream IP (TWAIN/ISIS driver) for high-quality image enhancement and PaperStream Capture for streamlined batch scanning operations.
The ADF can handle A4 documents, plastic cards, passports, envelopes, mixed batches, and long documents up to 6,096 mm in length.
The Ricoh fi-8170 supports both high-speed USB 3.2 Gen 1x1 and wired Gigabit Ethernet connectivity.
