A3 Paper Scanner Multi Feed
Plustek SmartOffice SC8016U
Features and Benefits
A3 Paper Scanner Multi Feed Plustek SmartOffice SC8016U is a departmental class A3 sized document scanner that features 80ppm (160 ipm) scan speed, 100 sheet feeder and 8,000 page per day duty cycle. Industry standard TWAIN driver ensures compatibility with almost any document imaging application.
- Auto Threshold
- Auto Rotate
- Auto Crop & Deskew
- Auto Mode
- Multi-Image Output
- Color Dropout
- Blank Page Removal
- Performance - Fast, Large feeder, High daily duty cycle
- Productivity - Handles a wide range of paper and card with no sorting
- Easy-to-Use
- Intelligent Misfeed Function
- Compatible with most imaging applications
- Responsible – Saves Energy
Specification
- General
|
Image Sensor |
CIS x 2 |
|
Light Source |
LED |
|
Optical Resolution |
600 dpi |
|
Hardware Resolution |
600 x 600 dpi |
|
Scan Modes |
Color: Input 48-bit, Output 24-bit Grayscale: Input 16-bit, Output 8-bit Black & White: 1-bit |
|
ADF Capacity |
1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 10 mm (0.4”) 2. 50 sheets (A3, 70 g/㎡ or 18 Lbs) 3. 20 sheets (Business Cards) 4. Plastic Card (Portrait Loading), Max. thickness under 1.2 mm, embossed cards can be scanned. Note: Maximum ADF capacity varies, depending upon paper weight. |
|
Scanning Speed ( ADF ) |
80 ppm/ 160 ipm (Grayscale/ B&W mode, 300 dpi, A4 Landscape) 45 ppm/ 90 ipm (Color mode, 200 dpi, A4 Landscape) 30 ppm/ 60 ipm (Color mode, 300 dpi, A4 Landscape) Note: Results may vary depending upon your scanning application, computer processor and system memory. |
|
Scanning Area (W x L) |
Max: 297 x 5080 mm (11.69” x 200”) Min: 13.2 x 13.2 mm (0.52” x 0.52”) |
|
Acceptable Paper Sizes (W x L) |
Max: 305 x 5080 mm (12” x 200”) Min: 50.8 x 63.5 mm (2” x 2.5”) |
|
Acceptable Paper Weight (Thickness) |
40 to 220 g/㎡ (10 to 58 Lbs) |
|
Multi-feed Detection |
With ultrasonic technology |
|
Daily Duty Scan ( Sheets ) |
8,000 |
|
Roller Lifetime (Scans) |
300,000 |
|
Pad Lifetime (Scans) |
100,000 |
|
Action Button |
4 Buttons: Up, Down, Scan, Standby 9 function keys: all customizable. |
|
Power Supply |
24 Vdc/ 2.7 A |
|
Interface |
USB 2.0 |
|
Net Weight |
6.57 Kgs (14.48 Lbs) |
|
Dimensions (W x D x H) |
436 x 262 x 266 mm (17.16" x 10.31" x 10.47") |
|
Protocol |
TWAIN Compliant |
|
OS |
Windows XP / Vista / 7 / 8 / 10 |
|
Hardware Requirements |
Pentium IV 3.2 GHz processor CD-ROM Driver One available USB Port (USB 2.0 recommended) 1GB RAM or higher recommended 800 MB free HDD space (1 GB or larger recommended) For longer documents/higher resolutions: Pentium IV, 3.2 GHz processor, 3 GB RAM |
