Document To Pdf Scanner
Plustek SmartOffice PS286 Plus
Features and Benefits
Document To Pdf Scanner Plustek SmartOffice PS286 Plus (Mac-compatible) workgroup class document scanner is designed with the image quality, paper handling and reliability required by the most demanding business users but at a price point attractive to home and SOHO users.
- Reliable Paper Handling
- Versatile Paper Handling Ability
- Easy to Use
- Compatible with most imaging applications
- Auto Threshold
- Auto Rotate
- Auto Crop & Deskew
- Color Dropout
- Blank Page Removal
Specification
- General
|
Image Sensor |
CIS x 2 |
|
Light Source |
LED |
|
Optical Resolution |
600 dpi |
|
Hardware Resolution |
600 x 600 dpi |
|
Scan Modes |
Color: Input 48-bit, Output 24-bit Grayscale: Input 16-bit, Output 8-bit Black & White: 1-bit |
|
ADF Capacity |
1. 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2"). 2. 20 sheets (Business Cards). 3. Plastic Card, Max. thickness under 1.2 mm. Note: Maximum ADF capacity varies, depending upon paper weight. |
|
Scanning Speed (ADF) |
25 ppm/ 50 ipm (Grayscale mode, 200 dpi, A4 Portrait) 25 ppm/ 50 ipm (B&W mode, 200 dpi, A4 Portrait) 8 ppm/ 8 ipm (Color mode, 200 dpi, A4 Portrait) 6 ppm/ 6 ipm (Color mode, 300 dpi, A4 Portrait) Note: Results may vary depending upon your scanning application, computer processor and system memory. |
|
Scanning Area (W x L) |
Max. 216 x 2500 mm (8.5” x 98.42”) Min. 13.2 x 13.2 mm (0.52” x 0.52”) |
|
Acceptable Paper Sizes (W x L) |
Max. 220 x 2500 mm (8.66” x 98.42”) Min. 50.8 x 50.8 mm (2” x 2”) |
|
Acceptable Paper Weight (Thickness) |
50 to 105 g/㎡ (14 to 28 Lbs) |
|
Daily Duty Scan ( Sheets ) |
1,500 |
|
Roller Lifetime (Scans) |
100,000 |
|
Pad Lifetime (Scans) |
20,000 |
|
Action Button |
3 Buttons: Up, Down, Scan. 9 Function Keys. All Customizable. |
|
Power Supply |
24 Vdc/ 0.75 A |
|
Interface |
USB 2.0 |
|
Net Weight |
1.66 Kgs (3.66 Lbs) |
|
Dimensions (W x D x H) |
263 x 128 x 148 mm (10.36" x 5.02" x 5.83") |
|
Protocol |
TWAIN Compliant |
|
OS |
Windows XP / Vista / 7 / 8 / 10 Mac OS X 10.8.x/ 10.9.x/ 10.10.x/ 10.11.x/ 10.12.x/ 10.13.x/ 10.14.x LINUX SANE for Systems Integrator. Please contact local sales. |
|
Hardware Requirements |
PentiumR IV 2.4 GHz processor DVD-ROM Driver One available USB 2.0 Port 1GB RAM (2GB or higher recommended) 2GB free HDD space (3GB or larger recommended) |
