Configuration

Functions: Copy, print, scan, optional fax

Colour: Yes

HDD: 256 GB SSD

Memory - standard: 6 GB—2 GB mainframe + 4 GB Smart Operation Panel
​
Operation panel: 10.1" Smart Operation Panel

Physical Dimensions

Physical dimensions (WxDxH)—mainframe: 587 x 701 x 913 mm
​
Weight—mainframe: 89.7 kg

Media Handling










​

Standard input capacity (sheets) : 1,200
​
Maximum input capacity (sheets) : 2,300

Standard output capacity (sheets):500
                                                              250—B4 or larger
Maximum output capacity (sheets): 1,625

Paper input configuration - standard: 2 x 550-sheet paper trays, 100-sheet bypass tray, 100-sheet ARDF, duplex unit

Paper output configuration - standard: 500-sheet face-down internal output tray

Supported media:-

• Tray 1

Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high gloss coated paper, coated paper

• Tray 2

Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high gloss coated paper, coated paper, envelope

• Optional trays

Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high-gloss coated paper, envelope, coated paper

• Bypass tray

Plain paper (paper type not displayed), recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, high-gloss coated paper, envelope, coated paper, label paper

Maximum paper size: SRA3
​
Media weight (g/m2): 52–300​

Connectivity



​

Interfaces - standard:Mainframe
10Base-T/100Base-Tx (Ethernet)
1000Base-T (Gigabit Ethernet)
USB Host Type A—2 ports
USB Type B—1 port
Smart Operation Panel
Bluetooth 5.21
 USB Host Type A—USB Flash memory
USB Host Type A—optional 1 port for USB keyboard

1—Cannot be used for printing

Interfaces - optional:
IEEE 802.11 a/b/g/n/ac Interface Unit Type M52
Device Server Option Type M52 (additional Ethernet/Gigabit Ethernet port)

Network protocols - standard:
TCP/IP (IPv4, IPv6)

Copy Features


​

Copy speed:   20 cpm

First copy time: 5.1 seconds—black and white
                             7.4 seconds—colour
Copy resolution:100, 200, 300, 400, 600 dpi—scanning
1,200 x 1,200 dpi (maximum)—printing
Zoom range:
25%–400% in 1% steps

Enlargement ratios
115%, 122%, 141%, 200%, 400%

Reduction ratios:
93%, 87%, 82%, 71%, 61%, 50%, 25%

Duplex copy:
Simplex to duplex, duplex to duplex—with ARDF, book to duplex, front and back to duplex

Book copy:
Booklet, magazine, layout and booklet

Print Features














​

Print speed colour: 20 ppm

Print speed black and white: 20 ppm

First print time: 4.5 seconds black and white, 7.0 seconds colour

Print resolution: 1,200 x 1,200 dpi

Page description languages (PDLs):Standard
PCL 5c, PCL 6, PostScript 3 emulation, PDF Direct emulation
Optional
Genuine Adobe PostScript 3, PDF Direct from Adobe
Printer drivers:Standard
PCL 5c, PCL 6, PostScript 3 emulation
Optional
Genuine Adobe PostScript 3
Duplex printing
Standard

Mobile printing
Yes

Scan Features









​

























​

Scan speed:Via ARDF
80 ppm—200 x 200 dpi, 300 x 300 dpi

Scan methods:Scan to USB, Scan to email, Scan to folder, Scan to URL, Scan to MSB, Scan to FTP, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF
Note: Optional OCR unit is required to support scanning to a searchable PDF.

Colour scanning:
Standard

Scan resolution:
100 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi, 1,200 dpi
Note: 1,200 dpi scanning is supported only with A5 or smaller paper size.

Scan to file types:Single- and multi-page TIFF
Single-page JPEG
Single- and multi-page PDF, PDF/A
Single- and multi-page high-compression PDF

Scan to email:Protocols
SMTP gateway, TCP/IP, POP, IMAP 4

Authentication
SMTP authentication, POP before SMTP authentication

Scan resolution
100 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi

Scan to email file types
Single-page
TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF

Multi-page
TIFF, PDF (default), PDF/A, high-compression PDF, encrypted PDF, searchable PDF
Note: Optional OCR unit is required to support scanning to a searchable PDF.

Scan to folderProtocols
SMB, FTP
Resolution
100 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi
Search for client folders
SMB—browsing directly to the designated folder
FTP—by folder name
Scan to folder file types
Single-page
TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF
Multi-page
TIFF, PDF (default), PDF/A, high-compression PDF, encrypted PDF, searchable PDF
Note: Optional OCR unit is required to support scanning to a searchable PDF.

TWAIN scanning:Scan mode
Standard, Photo, OCR, Filing
Note: Optional OCR unit required for OCR scanning.

Scan resolution
100–1,200 dpi
Note: 1,200 dpi scanning is supported only with A5 or smaller paper size.

Fax Features






















​

Fax types
G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax

Fax circuit
PSTN, PBX

Fax compatibilty
ITU-T (CCITT), G3—maximum 3 lines

Fax modem speed
2,400 bps–33.6 Kbps—G3, standard with automatic shift down

Fax compression methods
MH, MR, MMR, JBIG

Fax resolutionStandard mode
200 x 100 dpi—8 x 3.85 lines/mm

Detail mode
200 x 200 dpi—8 x 7.7 lines/mm

Super Fine mode
400 x 400 dpi—8 x 15.4 lines/mm
400 x 400 dpi—16 x 15.4 lines/mm
Note: Super Fine mode is supported with the optional SAF memory.

G3 fax transmission speed:
3 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission
3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission

Fax SAF memory capacity:
Standard
4 MB—approximately 320 pages

With optional SAF memory
60 MB—approximately 4,800 pages

Fax memory backup:
1 hour

Quick dials:
2,000 numbers

Security Features













​

Data Overwrite Security System (DOSS) - Standard:
Yes—optional HDD required

Encryption:SSD, PDF, Secure print, WEP, WPA
Authentication password
Encryption of data sent via Scan to email and Fax forwarding (S/MIME)

Authentication:802.1x wired authentication
Administrator authentication
IEEE 802.11i security (WPA2)
IPv6
Quota setting
User authentication—Windows and LDAP via Kerberos, basic, user code
WiFi Protected Setup (WPS) support

Supported Operating Environments



​

Windows:PCL 5c, PCL 6, and PostScript 3
Windows 8.1
Windows 10
Windows Server 2012
Windows Server 2012 R2
Windows Server 2016
Windows Server 2019
Windows Server 2022

Macintosh:
MacOS v10.15 or later—PostScript 3 only

Unix:
PCL 5c, PostScript 3
Sun Solaris, HP-UX, SCO OpenServer, Red Hat Linux, IBM AIX

SAP:
PCL 5c
R/3, S/4

Software and Solutions





​

Standard:
@Remote Embedded
Web Image Monitor

Optional:Streamline NX V3
GlobalScan NX
Enhanced Locked Print NX
Card Authentication Package
Mobile apps:
RICOH Smart Device Connector

Environmental Features

















​

Power source:
220–240 V, 50/60 Hz—Asia Pacific
110 V, 60 Hz—Taiwan

Power consumption:
1,700 W or less—maximum power, Asia Pacific
1,584 W or less—maximum power, Taiwan
411.8 W—operating power, black and white
465.3 W—operating power, colour
37.7 W—Ready Mode
0.3 W—Energy Saver Mode (Sleep Mode)

Typical Electricity Consumption (TEC):
0.20 kWh
Warm-up time24 seconds

Recovery time:From Energy Saver Mode
6.6 seconds
Green labels:
The Thai Green Label Scheme

Other environmental features:
Eco-friendly indicator, Energy Saver Timer, System Reset Timer
