Ricoh Image Scanner fi Series
fi-8820
Production Scanner
High-speed, heavy-duty production scanner equipped with a 500-sheet ADF, designed for centralized corporate and institutional scanning.
01
Load ADF
02
Clear Image
03
Staple Protect
04
Capture
120 ppm Speed
Blazing fast capture.
500-Sheet ADF
Large batch capacity.
100k Daily Vol
Built for production.
Touchscreen
4.3-inch intuitive UI.
Details
Specifications
Video
Brochure
Comprehensive Overview: fi-8820
Engineered for continuous production performance, the Ricoh fi-8820 handles massive daily duties with intelligent document protection, smooth paper ejection control, and elite image processing via PaperStream IP.
Advanced Feeding
- • Staple Protection: Detects stapled corners immediately to prevent device jams.
- • Straight Path Switch: Easily handles thick cards and folded media.
- • Ejection Control: Ensures orderly stacking of output paper.
Smart Ecosystem
- • Touchscreen Panel: Easy pre-set jobs and profile selections.
- • PaperStream IP/Capture: Industry gold standard driver cleanup.
- • Network Ready: Gigabit Ethernet & USB 3.2 support.
Technical Specifications
Performance
- Scan Speed (A4 Landscape): 120 ppm (Simplex) / 240 ipm (Duplex)
- Scan Speed (A4 Portrait): 95 ppm (Simplex) / 190 ipm (Duplex)
- Optical Resolution: 600 dpi
- Expected Daily Volume: 100,000 sheets
Interface & Size
- Interface: USB 3.2 Gen 1 / USB 2.0, Ethernet (1000BASE-T)
- Max Document Size: 304.8 x 431.8 mm (12 x 17 in.)
- Dimensions: 460 x 430 x 315 mm
- Weight: 23 kg
Media Handling
- ADF Capacity: 500 sheets
- Straight Scan Paper Weight: 20 to 570 g/m2
- U-turn Scan Paper Weight: 20 to 256 g/m2
- Multifeed Detection: Ultrasonic sensor & length check
Compatibility
- OS Support: Windows 10, 11 & Windows Server
- Software: PaperStream IP, PaperStream Capture
- Power Requirements: AC 100 to 240 V
- Display: 4.3-inch Touchscreen
Will be updated soon
Will be updated soon
Applications of Ricoh fi-8820 in Malaysia
The Ricoh fi-8820 production scanner delivers robust, high-volume performance for enterprise back-offices, government sectors, and service bureaus across Malaysia.
Government & Municipalities
- Massive record and citizen file conversion
- Reliable continuous multi-shift operation
- Stapled document detection prevents paper tearing
- Secure archival grade capture
Corporate Back-Offices
- High-capacity invoice and billing record processing
- Straight-path scanning for thick or special media
- Optimized paper ejection control
- Centralized high-speed enterprise workflow
Service Bureaus & BPO
- High daily throughput up to 100,000 sheets
- Precise multi-feed detection sensors
- Clear Image Capture technology for elite OCR
- Gigabit LAN & USB 3.2 network integration
Why Malaysian Enterprises Choose fi-8820
Organizations depend on the fi-8820 for high-volume durability and smart feeding protection:
- 120 ppm / 240 ipm landscape scan capability
- 500-Sheet ADF large volume feeder
- Stapled Document Detection stops misfeeds
- Clear Image Capture superior data extraction
- 4.3-inch Touchscreen for operator control
- Gigabit LAN & USB 3.2 connectivity options
The ultimate centralized production scanning solution for high-volume workloads across Malaysia.
Comparison Overview
| Feature | Ricoh fi-8820 | fi-7160 | Standard ADF |
|---|---|---|---|
| Scan Speed | 120 ppm (Landscape) | 60 ppm | 25-40 ppm |
| ADF Capacity | 500 Sheets | 80 Sheets | 50 Sheets |
| Daily Volume | 100,000 sheets | 40,000 sheets | 4,000 sheets |
| Touchscreen UI | 4.3-inch Touchscreen | No | No |
| Malaysia Supplier Support | Yes ✔ | Yes | Varies |
§ 03
Frequently asked questions
The fi-8820 scans up to 120 pages per minute (240 images per minute) in A4 landscape mode at 200/300 dpi.
The heavy-duty ADF holds up to 500 sheets of paper at a time for large batch processing.
Yes! Built-in stapled document detection stops the scanner immediately if a staple is found, preventing document damage.
We provide full installation, setup guidance, and maintenance support across Malaysia for the fi-8820 series.
The scanner supports Windows 10, Windows 11, and various Windows Server operating systems along with PaperStream IP driver integration.
The fi-8820 is robustly built for production environments with a recommended daily volume of up to 100,000 sheets per day.
