Pantum Office Colour A3 Photocopy Machine

Pantum CM270ADN 25PPM Photocopier

Pantum CM270ADN A3 Color Laser Multifunction Printer - Fotostat Seri Murni

Pantum CM270ADN A3 Color Laser Multifunction Printer (Ultra Series)

Optimize your corporate office productivity with economic 25 ppm A3/A4 color printing, scanning, and copying. Supported by full official warranty and local maintenance service from Fotostat Seri Murni Sdn Bhd in Petaling Jaya, Selangor.

💬 Direct WhatsApp Quote 📍 Visit PJ Showroom Map

1. Pantum CM270ADN Product Overview & Gallery

Pantum CM270ADN A3 Color Laser Multifunction Printer - Main View

Versatile 25 ppm Printing Speed: Cost-effective mono and vivid color printing up to A3 media size.
7-Inch Color Touch Screen: Smart touchscreen interface that streamlines job navigation and office workflow execution.
110-Sheet RADF Scanner: High-speed double-sided scanning up to 55 ppm directly to network shares, email, or USB storage.
High-Capacity CTO-2600 Toner System: Commercial-grade toner cartridges yielding up to 22,000 pages (Black) and 15,000 pages (CMY).

2. Pantum CM270ADN Technical Specifications

Specification Category	Technical Details
Core Functions	Print, Copy, Scan (Flatbed + 110-sheet RADF)
Print & Copy Speed	25 ppm (Color & Mono)
Duplex Print Speed	Mono: 21 ipm / Color: 18 ipm
First Print Out Time (FPOT)	Mono: 5.9 seconds / Color: 12 seconds
Processor Speed & Memory	1296 MHz Dual Core Processor / 4 GB RAM / 128 GB Standard Storage
Control Panel UI	7-Inch Smart Color Touchscreen Panel
Supported Media Sizes	A3, A4, A5, A6, B4, B5, Letter, Legal, Executive, Envelopes (60–256 g/m²)
Standard Paper Capacity	596 Sheets (500-sheet input tray + 96-sheet multipurpose tray)
Maximum Paper Capacity	Expandable up to 2,096 Sheets with optional paper feeder trays
Scanning Speed & Destinations	Up to 55 ppm; Scan to PC (SMB, FTP, WSD), Direct USB, Email (SMTP)
Connectivity Interfaces	Gigabit Ethernet (10/100/1000Base-T), USB 2.0/3.0, Direct USB Flash Drive Print/Scan
Monthly Duty Cycle	Maximum 100,000 pages/month (Recommended: 5,000 pages)
Physical Dimensions & Weight	590 x 659 x 771 mm / 70.55 kg

3. Overcoming High-Volume Color Printing Bottlenecks

❌ Challenge: Slow Processing of Complex Image & PDF Files

Large graphics files and multi-page A3 documents frequently jam legacy office copiers, creating workflow bottlenecks.

✔️ Solution: Dual-Core Engine & 4GB Hardware RAM

Powered by a 1296 MHz dual-core CPU with 4GB RAM and 128GB storage, the CM270ADN handles complex document jobs without lag.

❌ Challenge: High Replacement Costs & Constant Paper Refills

Standard small printers require frequent tray refills and constant toner swaps, driving up operational expenses.

✔️ Solution: Expandable 2,096-Sheet Tray & High-Yield Toners

Offers standard 596-sheet paper input expandable to 2,096 sheets paired with high-capacity 22,000-page CTO-2600 toners.

4. Ideal Applications & High-Output Workplace Solutions

Corporate Offices & Legal Firms

Steady 25 ppm speed and 55 ppm double-sided scanning cover daily administrative document and legal contract demands.

Architects & Design Studios

Provides precise A3 color fidelity for architectural blueprints, engineering schematics, and client presentations.

Commercial Copy & Print Hubs

Duty cycle up to 100,000 pages per month ensures reliable operation during heavy production cycles with low maintenance costs.

5. Why Choose Fotostat Seri Murni Sdn Bhd as Your Pantum Partner?

🏢 Premier Authorized Dealer & Service Center: Fotostat Seri Murni Sdn Bhd provides top-tier office printing solutions across Petaling Jaya, Subang Jaya, Shah Alam, and Kuala Lumpur.

📍 Local PJ Showroom Experience: Test print performance, evaluate touch screen responsiveness, and examine output quality at our physical showroom in Ara Damansara.

📍 Showroom Address: N-G-42, Ground Floor, Jalan PJU 1a/1, Ara Damansara, 47301 Petaling Jaya, Selangor.

🛠️ On-Site Warranty & Comprehensive Maintenance: Complete sales, leasing, toner supply, and rapid on-site technician service packages.

6. Enterprise Gigabit Networking, Confidential Security & Direct USB Operations

🔒 Confidential PIN Printing & Privacy Controls

Secure sensitive corporate documents and financial files using confidential PIN code printing to protect privacy before picking up prints.

🌐 Gigabit Ethernet & Direct USB Drive Walk-Up

Connect easily to enterprise local networks via 10/100/1000Base-T Ethernet, or walk up to print/scan directly using front USB flash drive ports.

7. CTO-2600 High-Yield Consumables & Cost Efficiency

The Pantum CM270ADN utilizes high-efficiency CTO-2600 series toner cartridges and CDO-2600 long-life drum units for low operating overheads:

CTO-2600K Black Toner: Yields up to 22,000 standard pages for economical monochrome printing.
CTO-2600 C/M/Y Color Toners: Yield up to 15,000 standard pages each for vibrant color documents.
CDO-2600 Long-Life Drum: Up to 126,500 pages (Black) and 96,000 pages (Color) to minimize replacement maintenance.

8. Frequently Asked Questions (Pantum CM270ADN FAQ)

Q: Does the Pantum CM270ADN support A3 paper size printing and scanning?

A: Yes, the CM270ADN fully supports A3, A4, A5, B4, B5, and custom paper formats for printing, copying, and scanning via its flatbed and RADF feeder.

Q: What are the exact print speed and scanner performance specs?

A: The CM270ADN provides up to 25 pages per minute for color and mono printing/copying, with RADF double-sided scanning speeds reaching up to 55 ppm.

Q: Can I lease or rent the Pantum CM270ADN from Fotostat Seri Murni?

A: Yes! We offer flexible purchase, lease, and meter-rate maintenance plans for businesses across Petaling Jaya and Greater KL.

Q: Where can I buy genuine CTO-2600 replacement toners in Petaling Jaya?

A: Original CTO-2600 black and color cartridges, drum units, and waste toner boxes are stocked directly by Fotostat Seri Murni Sdn Bhd in Ara Damansara.
