HP DesignJet T650
HP DesignJet T650 Wireless
Large Format Plotter Printer
A1 Plotter Printer, 24 inch Printer, Large Format Plotter HP DesignJet T650 - 24"/36", with convenient 1 - Click Printing
- 24-in: 26 sec/page on D, 81 D prints per hour
- 36-in: 25 sec/page on D, 82 D prints per hour
- Dye-based (C, M, Y); pigment-based (K)
- Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter
- Compliant with Class B requirements, including: USA (FCC rules)
- Specifications
- Brochure
- Video
|
Print |
Print speed
Technology: HP Thermal Inkjet Margins
Page Yield: 20 ml of ink yields 101 A1/D pages, taking into account maintenance routines (Calculation done taking into account two normal printhead cleanings and ink on an A1/D CAD drawing with black and color lines and a pixel coverage of 5.2%.) Ink drop: 5.5 pl (C, M, Y); 12 pl (K) Printheads: 1 (cyan, magenta, yellow, black) Printhead nozzles: 1376 Line accuracy: ±0.1% (±0.1% of the specified vector length or ±0.2 mm (whichever greater) at 23ºC (73ºF), 50-60% relative humidity, on A0/E printing material in Best or Normal mode with HP Heavyweight Coated roll feed and Original HP inks.) Minimum line width: 0.0008 in (0.02 mm) Max optical density: 8 L* min/2.10 D (With HP Premium Instant Dry Photo Gloss media with Original HP inks.) |
|
Media |
Handling: Sheet feed, roll feed, automatic sheet feeder, media bin, automatic horizontal cutter Roll size
Thickness: Up to 11.8 mil |
|
Applications |
Line drawings; Presentations; Renderings Memory: 1 GB Hard disk: None |
|
Connectivity |
Interfaces: Gigabit Ethernet (1000Base-T), Hi-Speed USB 2.0, Wi-Fi 802.11 Print languages (standard): HP-GL/2, HP-RTL, CALS G4, JPEG, URF Drivers: Raster driver for Windows and macOS |
|
Dimensions (w x d x h) |
Printer
|
|
Weight |
Printer
|
|
HP Software and solutions |
HP Click, HP Smart app, HP Print Preview for Windows, HP Easy Start, HP DesignJet Utility for Windows, HP Support Assistant Remote print enabled: Yes One-click multi-size printing: Yes |
|
Environmental ranges |
Recycled plastic in printer: 30% Operating temperature: 41 to 104ºF Operating humidity: 20 to 80% RH Operating altitude: Up to 9843 ft Storage temperature: -13 to 131ºF (-25 to 55ºC) |
|
Acoustics |
Sound pressure: 42 dB(A) (operating), <16 dB(A) (idle) Sound power: >5.8 B(A) (operating), <3.4 B(A) (idle) |
|
Power |
Consumption: <35 W (printing), <5.6 W (ready), <2.1 W (sleep), <0.2 W (standby) Requirements: Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz (±3 Hz), 1200 mA max |
|
Certification |
Safety: USA and Canada (CSA certified) Electromagnetic: Compliant with Class B requirements, including: USA (FCC rules), Canada (ICES) Environmental: ENERGY STAR; WEEE; ErP; EPEAT Gold |
Find Out More About HP DesignJet T650 Wireless
