Projector type: Short throw
What's included:

• CD-ROM: Includes instruction manual in English and Chinese
• Quick start guide: Yes
• Signal cable: RGB cable
• Power cord: 1.8 metres, 220 V
• Conversion adapter: No
• Carrier bag: No
• Lens cap: Yes
• Remote control: Yes
• Battery for remote control: CR2025 x 1

Physical dimensions (WxDxH)—mainframe: 288 x 220 x 86 mm
Weight—mainframe: 2.8 kg or less

Projection system: DLP
Contrast:

• 2,000:1—native
• 10,000:1—High Contrast Mode (with ImageCare)

Aspect ratio: 4:3
Brightness: 3,000 lumens
Resolution: 1,024 x 768 pixels (XGA)
Light source life: 3,500h/5,000h (Eco)/10,000h (ImageCare)
Lamp type: High-pressure mercury lamp
Lamp wattage: 240 W
Lens focal length: f:7.26 mm
Lens aperture: F:2.8
Focus method: Manual
Colour reproduction: 1,073,000,000 colours
Projection size: 40–200 inches
Projection distance: 0.51–2.54 m
Projection ratio: 0.617:1/80 inches at 1.0 m
Keystone correction: Supported—manual, vertical
Projector modes: Standard, Rear, Ceiling, Rear ceiling
Input signals:
Analogue RGB signal (real)

• XGA (1,024 x 768), SVGA (800 x 600), VGA (640 x 480)

Analogue RGB signal (vertical)

• UXGA (1,600 x 1,200), SXGA (1,280 x 1,024), WXGA (1,280 x 800)

Input signal

• NTSC-M, PAL, SECAM, NTSC-4.43, PAL-M, PAL-N, NTSC-J, PAL-60

Analogue RGB frequency

• 15k–91.1 kHz—horizontal
• 24–85 Hz—vertical

3D support: Yes
Speaker: 8 W
Other supported features: Automatic brightness control (Auto ImageCare), Closed captioning, USB firmware updates, Front exhaust fan

Interfaces - standard:

• Computer 1 input terminal: Mini D-SUB 15-pin x 1
• Computer 1 monitor output terminal: Mini D-SUB 15-pin x 1
• Computer 2 input terminal: Mini D-SUB 15-pin x 1
• Video terminal: RCA 1-pin x 1
• PC control and service: D-SUB 9-pin x 1 (RS-232C)
• Audio 1 and Audio 2 input terminals: 3.5 mm mini jack x 2
• Audio output terminal: 3.5 mm mini jack x 1
• HDMI terminal: HDMI x 1
• Service terminal: USB Type Mini B x 1 for firmware upgrades

Supported languages:

• Menu languages : English, German, French, Italian, Spanish, Polish, Swedish, Thai, Portuguese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Norwegian, Czech, Hungarian, Dutch, Kazakh, Hindi
• Instruction manual: English and Chinese

​Power source: 100–240 V, 50/60 Hz
Power consumption:

• 306 W—maximum
• 295 W—Standard Mode
• 240 W—Eco Mode 1 and 2
• 0.5 W or less—Standby

Sound power level:
Operating environment of 23ºC

• 38 dB or less—Standard Mode
• 32 dB or less—Eco Mode 1
• 29 dB or less—Eco Mode 2

Environmental standards:

• Restriction of Hazardous Substances (RoHS)
• REACH regulations
• EuP (Lot6)
• ErP (Lot19)
• Directive 2006/66/EC (batteries and accumulators)
• Directive 2005/20/EC (packaging and waste)
• Waste of Electrical and Electronic Equipment (WEEE)
• Taiwan Battery Regulation

Green labels: Taiwan Green Mark
Safety standards:

• EN60950-1(TUV)
• IEC60950-1 (CB attestation)
• IEC60950-1 (PSB)
• BIS (Bureau of Indian Standards)

Electromagnetic Compatibility (EMC) standards:
Electromagnetic Interference (EMI) standards

• EN55022
• EN55024 (CE Marking)
• EN61000-3-2
• EN61000-3-3
• AS/NZS CISPR 22 RCM (Regulatory Compliance Mark)
• Hong Kong EMC (Electromagnetic Compatibility)

Other environmental features: Eco Mode

​Projection Calculator:

• Use this convenient tool to estimate the throw distance for selected Ricoh projectors. It is not intended to provide exact measurements.
• Please click the link to visit the Projection Calculator.
