Configuration

Functions: Copy, print, scan, optional fax
Colour: Yes
HDD: 640 GB (320 GB x 2)
Memory - standard: 4 GB
Operation panel: 10.1-inch Smart Operation Panel (G2.5)

Physical Dimensions

Physical dimensions (WxDxH)—mainframe: 750 x 880 x 1,225 mm
Weight—mainframe: 250 kg or less

Media Handling










​

Standard input capacity (sheets): 3,700
Maximum input capacity (sheets): 8,100
Maximum output capacity (sheets): 3,500
Paper input configuration - standard: 1,250-sheet x 2 tandem tray, 2 x 550-sheet paper input trays, 100-sheet bypass tray, 220-sheet SPDF, Duplex unit
Supported media:

• Plain paper1, recycled paper, colour paper, special paper 1–3, letterhead, pre-printed paper, pre-punched paper, bond paper, card stock, thin paper, plain paper 1–2, middle thick, thick paper 1–4
• 1—Not displayed as paper type

Maximum paper size: 13" x 19.2"
Media weight (g/m2): 52.3–300

Connectivity



​

​Interfaces - standard:
Mainframe

• 10Base-T/100Base-TX/1000Base-T (Gigabit Ethernet)
• USB Host Type A—2 ports
• USB Device Type B—1 port

Smart Operation Panel

• IEEE 802.11 b/g/n (Wireless LAN)1
• Bluetooth 4.22
• SD Card Slot—SDHC memory card
• USB Host Type A—USB Flash memory
• USB Host Type A—1 port for USB keyboard (optional)2
• USB Host Type mini B—for NFC card reader (optional)2
• microSD card slot—ROM storage expansion2
• NFC Tag2
• 1—Limited printing for a peer-to-peer mobile device via RICOH Smart Device Connector
• 2—Cannot be used for printing

Interfaces - optional:

• IEEE 1284
• Wireless LAN (IEEE 802.11 a/b/g/n)1
• Device Server Option Type M37 (additional NIC port)
• Copy Connector Type M25
• 1—Cannot be used with Bluetooth at the same time

Network protocols - standard: TCP/IP (IPv4, IPv6)

Copy Features


​

Copy speed: 65 cpm
First copy time

• 5.5 seconds—black and white
• 7.5 seconds—colour

Copy resolution: 600 x 600 dpi
Zoom range: 25%–400% in 1% steps
Enlargement ratios: 400%, 200%, 141%, 122%, 115%
Reduction ratios: 93%, 82%, 75%, 71%, 65%, 50%, 25%
Duplex copy: Simplex to duplex, duplex to duplex—with SPDF, book to duplex, front and back to duplex
Book copy: Booklet, magazine, layout, and booklet
ID card copy: Supported

Print Features














​

Print speed colour: 65 ppm
Print speed black and white: 65 ppm
First print time: 5.5 seconds or less—black and white; 7.5 seconds or less—colour
Print resolution:

• 1,200 x 4,800 dpi—when printing
• 2,400 x 4,800 dpi—when copying

Page description languages (PDLs):

• Standard: PCL 5c, PCL 6, PostScript3 emulation, PDF Direct emulation
• Optional: Adobe PostScript 3, Adobe PDF Direct, XPS, IPDS

Printer drivers:

• Standard: PCL 5c, PCL 6, PostScript3 emulation
• Optional: Adobe PostScript 3

Duplex printing: Standard
Mobile printing: AirPrint, Mopria®, RICOH Smart Device Connector
Print from USB/SD: Supported

Scan Features









​

























​

Scan speed:

• A4 LEF via SPDF
• 120 ipm—simplex
• 240 ipm—duplex

Scan methods: Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP), Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded)
Colour scanning: Standard
Scan resolution: 100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi, 1,200 dpi
Scan to file types:

• Single- and multi-page TIFF
• Single-page JPEG
• Single- and multi-page PDF, PDF/A
• Single- and multi-page High-Compression PDF

Scan to email:
Protocols: SMTP gateway, TCP/IP
Authentication: SMTP authentication, POP before SMTP authentication
Scan resolution: 100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi
Scan to email file types:

• Single-page: TIFF, JPEG, PDF, PDF/A, High-Compression PDF, Encrypted PDF, Searchable PDF
• Multi-page: TIFF, PDF, PDF/A, High-Compression PDF, Encrypted PDF, Searchable PDF
• Note: Optional OCR unit is required to support scanning to a searchable PDF.

Scan to folder:
​Protocols: SMB, FTP, WSD (Web Services on Devices for Scanning), DSM
Security: Client folder logon, transmission encryption of logon name and password
Resolution: 100 dpi, 150 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi
Search for client folders:

• SMB—browsing directly to the designated folder
• FTP—by folder name

Scan to folders file types:

• Single-page: TIFF, JPEG, PDF, PDF/A, High-Compression PDF
• Multi-page: TIFF, PDF, PDF/A, High-Compression PDF

TWAIN scanning:
Scan mode: Standard, Photo, OCR, Filing
Scan resolution: 100–1,200 dpi

Fax Features






















​

Fax types: G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
Fax circuit: PSTN, PBX
Fax compatibilty: ITU-T (CCITT), G3—maximum 3 lines
Fax modem speed: 2,400 bps–33.6 Kbps—G3, standard with automatic shift down
Fax compression methods: MH, MR, MMR, JBIG
Fax resolution:
Standard mode

• 200 x 100 dpi—8 x 3.85 lines/mm

Detail mode

• 200 x 200 dpi—8 x 7.7 lines/mm

Super fine mode

• 400 x 400 dpi—8 x 15.4 lines/mm
• 400 x 400 dpi—16 x 15.4 lines/mm
• Note: Super fine mode is supported with the optional SAF memory.

G3 fax transmission speed:

• 2 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission
• 3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission

Fax SAF memory capacity:

• Standard—4 MB
• With optional SAF memory—60 MB

Fax memory backup: 1 hour
Quick dials: 2,000 numbers

Security Features













​

Data Overwrite Security System (DOSS) - Standard: Yes
Data Overwrite Security System (DOSS) - Optional: Type M19—available for customers who require their devices to comply with ISO 15408 Common Criteria certification
Encryption: PDF, Secure print, WEP, WPA encryption
Authentication password encryption: Encryption of data sent via Scan to email and Fax forwarding (S/MIME)
Authentication:

• 802.1x wired authentication
• IEEE 802.11i security (WEP, WPA)
• IPv6
• Network user authentication
• Quota setting/Account limit
• User authentication—Windows and LDAP via Kerberos, basic, user code
• User code authentication
• Wi-Fi Protected Setup (WPS) support

Supported Operating Environments



​

Windows:

• Windows 7
• Windows Server 2008
• Windows Server 2008 R2
• Windows 8.1
• Windows Server 2012
• Windows Server 2012 R2
• Windows 10
• Windows Server 2016
• Windows Server 2019

Macintosh: OS X Native v10.12 or later—PostScript 3 only
Unix:

• Sun Solaris—10
• HP-UX—11.x, 11iv2, 11iv3
• Red Hat Linux—Enterprise v4, v5, v6
• SCO OpenServer—5.0.7, 6.0
• IBM AIX—6.1, 7.1, 7.2

SAP:

• Environment—R/3, S/4
• Platform—SAP R/3 (Release versions 3.0 and higher), SAP R/3 Enterprise, mySAP ERP (2004 and higher), SAP HANA
• Page Description Language (PDL)—PCL
• Character set—Latin-1, Latin-2, Unicode
• Barcode fonts—Code 128, Code 39, Code 93, Codabar, 2 of 5 interleaved/Industrial/Matrix, MSI, USPS Postnet, UPC/EAN
• OCR fonts—OCR A, OCR B
• Other supported features—Input/Output Bin, Duplex, Stapling, Punching, Resolution, Collation, EconoMode / TonerSaving, Smoothing, Page Protect, Auto Tray Change/Optional Tray Select, User Authentication

Software and Solutions





​

Standard:

• @Remote Embedded
• Web Image Monitor

Optional:

• @Remote Office
• @Remote Enterprise Pro
• Global Scan NX
• Card Authentication Package
• Enhanced Locked Print NX
• Device Manager NX Lite
• Device Manager NX Accounting
• RICOH Streamline NX

Mobile apps: RICOH Smart Device Connector

Environmental Features

















​

Power source: 220–240 V, 12–10 A, 50/60 Hz
Power consumption:

• 2,400 W or less—maximum power
• 1,147.4 W or less—operating power, black and white
• 1,270 W or less—operating power, colour
• 185.86 W—Ready Mode
• 168 W—Low Power Mode
• 0.74 W—Energy Saver Mode (Sleep Mode)

Typical Electricity Consumption (TEC): 1.201 kWh (nominal), 1.224 kWh (guaranteed)
Warm-up time: 40 seconds
Power saving mode:

• 45 minutes shift time—Energy Saver Mode (Sleep Mode)
• 15 minutes shift time—Low Power Mode

Recovery time:

• 38 seconds—Energy Save Mode (Sleep Mode)
• 7.9 seconds—Low Power Mode

Other environmental features: Eco-friendly indicator screen, System reset timer
