A0 3 in 1 Multi Function Printer Plotter
Epson SureColor SC-T5430M
The T-series printers heighten your ideas by showcasing them in a big way with its stand-out performance, impeccable precision and exceptional engineering. Engineered for precision and reliability, the printer comes with the PrecisionCore printheads and UltraChrome XD2 ink to help businesses go big on their plans.
- 36-inch Large Format multifunction technical printer with scanning capability
- Top class line accuracy
- Durable and vibrant printouts with Epson all-pigment UltraChrome XD Ink
- Outstanding speeds of up to 2 A1 prints per minute
- Specifications
- Brochure
- Video
|
Printing: |
Printing Technology: Printhead: PrecisionCore TFP Printhead 1.3" Nozzle Configuration: 3,200 nozzles (800 nozzles x 4 channels x 1 head) Maximum Print Resolution: 2,400 X 1,200 dpi Minimum Ink Droplet Size: 4.0pl Print Speed: CAD (A1): 22 sec |
|
Roll Media Handling: |
Maximum Roll Diameter: 2/3" core Maximum Roll Weight: Max. 170 mm/12kg Media Thickness: 0.8mm |
|
Ink: |
Ink Type: Epson UltraChrome XD2 Pigment Ink Colours: 4 Colours - Cyan, Magenta, Yellow, Black Ink Capacity: Cyan, Magenta, Yellow and Black: 110ml Cyan, Magenta, Yellow and Black: 350ml |
|
Printer Details: |
Options: Roll Feed Spindle (36") |
|
Control Panel: |
Control Panel: 4.3" Touch Screen |
|
Consumables: |
Maintenance Box: Yes Auto Cutter Spare Blade: Yes |
|
Power: |
Power Consumption: Ready: Approx. 13W; Sleep: Approx. 1.6 W Operating: Approx. 38W Power Off: Approx 0.25W Requirement: Frequency: 50/60Hz AC 100-240V Recommended Operating Temperature & Humidity: Operating: 20 to 80% (no condensation) Storage: 5 to 85% (no condensation) |
|
General: |
Dimensions: 1,385 x 966 x 1,060 mm (WxDxH) Warranty: 3-years warranty Weight: 89kg (without ink) Memory: 1GB + 8GB*2 |
|
Connectivity: |
Included Software: Windows Install Navi - Printer driver - EpsonNet Setup - EpsonNet Print - EpsonNet Config -Epson Software Updater - LFP Print Plug-in for Office - Epson manuals Mac Setup Navi Printer Interfaces: Super-Speed USB 100BASE-TX /1000BASE-T/IEEE802.11 b/g/n Printer Languages : ESC/P raster HP-GL/2HP RTL |
|
Paper Handling: |
Maximum Paper Width: Roll: 254 mm to 914 mm Cutsheet: 210 mm to 914 mm Media Thickness: Up to 0.3 mm Auto Sheet Feeder / Cutsheet: 0.08 mm to 0.3 mm Media Type: Inkjet Coated Paper, Tracing Paper, Plain Paper Side Margin: 3mm Borderless Print: Yes Auto-Sheet Feeder: N/A |
|
Acoustic Noise Level: |
Sound Pressure Level: Operating: Approx. 50dB(A), Sleep: Approx. 32dB(A) Sound Power Level: Operating: Approx. 7.5B(A) |
|
Printer Width: |
Printer Width: 36" |
|
Scanner Integration (Scanner): |
Sensor: CIS with RGB Filters Light Source: Dual Optical Resolution: 600dpi Scan Speed (200dpi): Colour: 4.5 ips Mono: 7.5 ips Maximum Scan Length: 30.5m |
|
Printer Management: |
Printer Management: Epson Edge Dashboard Accounting Tool |
