• Provides automatic inline document folding with the ability to deliver folded output in several different patterns. Ideal for finished documents such as newsletters, brochures, menus, and marketing materials.
• Folding types:

          Single sheet mode
          Half-fold, Z-fold,
          Letter fold-in, Letter fold              out
         Multiple sheet mode (up             to 3 sheets)

• Letter fold-in, Letter fold out
• Paper size: A4—13" x 19.2"
• Paper weight:
• 64–105 g/m2—single sheet mode
• 64–80 g/m2—multiple sheet mode
• Power source: 220–240 V
• Power consumption: 60 W or less
• Dimensions (W x D x H): 209 x 730 x 1,000 mm
• Weight: 45 kg or les

• Allows to handle large volume of output and move it with a roll-away cart that is included as standard. Up to 2 stackers can be configured in one system. An additional roll-away cart is available.
• Proof tray:
• Stack capacity: 250 sheets
• Paper size:


          A6–13" x 19.2"

• Paper weight:52–470 g/m2
• Note: 487–700 mm banner sheet supported when finisher is not attached.
• Shift tray:
• Stack capacity: 5,000 sheets—A4–13" x 19.2"; 2,500 sheets—B5
• Paper size: 139.7 x 139.7 mm–331 x 488 mm (13" x 19.2")
• Paper weight: 52–470 g/m2
• Note: Actual supported paper weight is dependent on the mainframe.
• Output jogger: Standard
• Roll-away cart: Includes 1 cart. Additional cart is optional.
• Door lock: Optional; includes a bracket for the lock
• Dimensions (W x D x H): 900 x 730 x 1,010 mm
• Weight: 131 kg or less: 135 kg or less with roll-away cart
• Power source: 220–240 V, 50–60 Hz, 0.8 Amps
• Power consumption: Less than 120 W

• Creates flat-fold, saddle-stitched booklets, and folded unstapled booklets with a professional appearance and no manual intervention. Comes with dual shift trays for ‘non-stop delivery.’ Punch option is available.
• Capacity: 3,500 sheets (dual shift tray)
• Paper size:
• Without Z-fold
• Max. 330.2 x 487.7 mm (13" x 19.2"), min. 139.7 x 139.7 mm
• 330.2 x 1,260 mm—with banner sheet output tray
• With Z-fold
• Max. 304 x 457 mm, min. 139.7 x 139.7 mm
• Paper weight:
• Without Z-fold
• 40–350 g/m2 (upper tray), 40–470 g/m2 (lower tray)
• With Z-fold
• 64–105 g/m2
• Staple capacity: 100 sheets (A4); 50 sheets (A3)
• Staple positions: top, bottom, 2 staple, top slant
• Staple paper weight: without Z-fold: 64–80 g/m2; with Z-fold: 64–105 g/m2
• Saddle stitch staple: 30 sheets (120-page booklet) with 80 g/m2 paper
• Optional punch unit PU5030 available
• Dimensions (W x D x H): 1,113 x 730 x 1,490 mm ; 1,334 x 730 x 1,622 mm with banner sheet option Type S6; 1,876 x 730 x 1,617 mm—with banner sheet option Type S14 (installed on the upper tray); 1,926 x 730 x 1,617 mm—with banner sheet option Type S14 (installed on the lower tray)
• Weight: 160 kg
• Power consumption:


           150 W
